DC 10-30V Motor Speed Controller Reversible Switch PWM Adjustable

  DC 10-30V Motor Speed Controller Reversible Switch PWM Adjustable Regulator 80W Features:

CCM2 DC Motor Speed Regulator controls the speed of a DC motor by adjusting Pulse-Width-Modulated (PWM) Control the forward or reverse direction and the stop of DC motor by switch Incorporate a high power MOSFET and a high quality potentiometer
Adjustable speed range is from 5%-95% (both Positive and Negative DC output) Suitable for the DC motor (or DC load) within 3A

Main technical parameters:

• Input supply voltage: 10V-30VDC(max)

• PWM frequency: 500Hz; Duty Cycle adjustable: 5%-95%

• Item size: 2.9*1.85*1.1 inches; Net weight: 2.4 ounces

• The maximum output power: Apply for the dc motor within

12V40W to 24V80W.

• The maximum continuous output current :3A; Peak current is 4A.





Operating instruction:

Before you attempting to wire the controller, make sure power is off.

WARNING: DO NOT REVERSE POSTIVE AND

NEGATIVE POWER LOADS.THIS WILL DAMAGE

THE CONTROLLER. TO CHANGE MOTOR DIRECTION,

INTERCHANGE THE POSITIVE AND NEGATIVE

WIRES OF MOTOR.

1. Connect wires refer to the “wiring diagram” .

2. Turn on the power, and adjust the potentiometer and the switch.

3. The green LED lights, the power is OK.

The red LEDs indicate the motor speed and direction.



Package Including:

1 x DC Motor Speed Controller
